Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch

Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch

    • Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch
    • Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch
    • Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch
  • Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch

    Product Details:

    Place of Origin: China
    Brand Name: symcode
    Certification: CE / RoHS / FCC
    Model Number: MJ-2877

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Packaging Details: Carton box
    Delivery Time: Sample order:1-3 days / Bulk order:7-15days
    Payment Terms: T/T, Western Union, L/C, D/A, D/P
    Supply Ability: 50,000pcs per month
    Contact Now
    Detailed Product Description
    Reading Mode: CMOS Decode: 2D
    Interface: BLUETOOTH Color Depth: 32-bit
    Communication Mode: SPP, HID Distance: 30 Meters (visual Distance)
    Sensor: 2500 Pixels Battery: 3.7V 1000mA Li-ion
    Bluetooth Module: 4.0 Humidity In Storage: 20 - 85% (non-condensing)
    Humidity In Operation: 20 - 85% (non-condensing)

    Hot Selling New Bluetooth Wireless Handheld Portable

    2D Barcode Scanner Factory





    Main Features:

    - Three scanning modes, including continuous scan mode, manual mode, auto off mode

    - Long working time with a full single charge

    - The sound size of prompt tone can be adjusted by setting the size of the bar code

    - Built-in 1000mAh rechargeable lithium-ion battery supplies 24hrs working time and it can be fully recharged for 4hrs, standby time up to 36 hours

    - HID / SPP Mode and scan switch

    - Built-in 512KB memory storage mode, it can store more than ten thousand pieces of information

    - Built-in Bluetooth disconnected 2KB memory as temporary data, it can store approximately 110 pieces of data when using

    - It can be set up by reading the bar code to change the data transmission format, edit the data and bar code type



    Specification
    Mechanical Length:57.8mm, Width: 42.3mm, Height:16.4mm
    Weight 40g
    Electrical Power: DC5V Typical: 75mA DC5V
    CPU 32bit ARM CPU
    Data storage 100KB for offline mode: 6000 15 bytes barcodes(Other flash is optional).
    Working mode Bluetooth mode, USB mode, offline mode and RS232 mode(optional)
    Scan mode Good-read off, Momentary, Alternate, Continuous, Host
    Artificial light immunity 100,000 lux
    Scanner performance

    Sensor Type: CMOS

    Scanner Rate: 100 times

    Scanner Angle: ±50°,±65°,±35°(skew, pitch, Roll)

    Contrast: >20%

    Decode Speed: 100 times per second

    Battery power

    Internal Battery: Changeable 600mAh Li-ion Battery, Standby 5 days, working time after full charge with good decode as below:

    Continuous trigger scanning interval Decoding number Working time
    1S 15500 4.3hours
    5S 5550 7.7hours
    10S 3590 10hours

    Charge Time: About 1.5hours.



    Barcode Type UPC-A, UPC-E, EAN-13, EAN-8, ISBN/ISSN, Code 39, Code 39 full ASCII,Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5,Codabar (NW7), Code 128, Code 93, Code 11(USD-8), MSI/Plessey,UK/Plessey, UCC/EAN 128, China Post, GS1 DataBar (formerly RSS) variants



    Portable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan SwitchPortable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan SwitchPortable 2D Wireless Handheld Barcode Scanner SPP Mode And Scan Switch
